CD 840 Repair
CD 840 , mains connector missing pin I have some spare Broken solderjoints Processor ...
CD 840 , mains connector missing pin I have some spare Broken solderjoints Processor ...
CD 100 – Audio dropouts and digital distortion. Some quick test , Reading TOC playing and Distortion free audio Nice Clear and stable eye-pattern 😉 1,2 volt p/p Resoldered , testing again...
Replaced the Tactile swithes Bitstream AudioBoard Headphone Amp, 4 x 100µf , some became 1k resistors and others 27µf 😉 More Bad Blue Axial Caps
CD 880 Refurbisch early version Dus Cleaning After brushing , now replace all small caps 47µf is 10µf Some early version modificaties Recap Main board Modification P203 firmware and a modification...
What happend here made the XLR unbalanced Relay L504 is missing ? Capicitors remover and Resistors Aha, the output transformers for the Balanced output are not in use..? On this board there are also...
I have some spare part , a other PCB or a spare CD 104 powersupply with nice audio connectors Pick and place error SMD components on...
This CD 202 has been recapped but is not working 😉 let see what we can do. the powersupply 2200 µf replaced by 4700 µf , more is beter ? 1800 µf instead off...
Bought a 2nd hand neat defective CD 104 full of surprises Audio Board OK…? NOS modification OPA 2604AP Filtercaps TDA1540 Reed-relais bypasses Cinch chassis -24 volt regulator have...
Revision Defective CD 100 Attic Find , only the repeat led will turn-on. Broken Solderjoint transitor lasersupply
